PDF set with architectural drawings and details ready for construction
The Onyx Cabin
USD 1550
About this package
Coming Soon: Spacious 87 sqm cabin design + distinct kit-of-parts designed for sub-tropical areas. Estimated construction value of USD 55 000+
Delivery
1 - 2 weeks
What You'll Receive
- 1:50 floor plan, x2 sections, x4 elevations
- 1:20 Detail of the wall details, roof details + floor details
- Engineer approved roof structure layout + details
- 1:50 plumbing + electrical floor plan
- Water conservation system
- Material shopping list + overall accurate sizes
Perfect For
- Easy Material Shopping
- Easy Construction in Remote areas
- Self Build Starter Home for 2pax
